BeiYin company was established in the year of 1988,as a special speaker manufactory and the local industry leader,we have a variety of speakers and sale worldward. Our regular products are micro speaker,multimedia speakers,professional speaker units |
| |
|
|
 |
|
| Tweeter(BYG25-4) Model: BYG25-4
Size:
Voice Coil Impedance: 6 ohm
Resonant Freq. (F0): 1500 Hz
Output S.P.L.: 88 dB
Rated Power Input: 15 W
Max Power Input: 30 W
Freq. Response: F0~20 k Hz
Magnet Size: Dia.24*3-N35H 23*4*3-N35H mm
Voice Coil Size: Dia.25.4mm
Total Weight: 64 g |
 | Woofer(BY200-7) Model BY200-7
Nominal Impedance : 8(Ohm)
Nominal Power:30(W)
Max power: 60(W)
Resonant Freq. (fo): 38(Hz)
Rated Freq. Range: fo~3500(Hz)
Sound Pressure Level: 88 (dB/1W/1M)
Magnet Size: 120*60*20 (mm)
Magnet Weight: 848 (g)/30 (oz)
Speaker Weight : 2250 (g)
|
 | Tweeter(BYG100-2) Model BYG100-2
Nominal Impedance: 6 (Ohm)
Nominal Power: 15 (W)
Max power: 30 (W)
Rated Freq. Range: 2000~ 20,000(Hz)
Sound Pressure Level: 87+/-3(dB/1W/1M)
Voice Coil:dia 25.5mm
Magnet Size: 70 x 32 x 10 (mm)
Outside Diameter: 100 x 100 x 22mm
Speaker Weight: 370 (g)
|
 | Tweeter(BYG100-1) Model BYG100-1
Nominal Impedance: 6 (Ohm)
Nominal Power: 15 (W)
Max power: 30 (W)
Rated Freq. Range: 2000~ 20,000(Hz)
Sound Pressure Level: 87+/-3(dB/1W/1M)
Voice Coil:dia 25.5mm
Magnet Size: 70 x 32 x 10 (mm)
Outside Diameter: 100 x 100 x 27mm
Speaker Weight: 369 (g)
|
|
|
|
